Glass Fiber Syringe Filters

Glass Fiber Syringe Filters Glass Fiber Syringe Filters
Roll over image to zoom in Click on image to zoom *labels and containers may vary from image shown.
Glass Fiber Syringe Filters

Glass Fiber Syringe Filters

$87.00
No Reviews Yet   | Questions
Select size:
25mm
25mm
$87.00
$87.00

About Glass Fiber Syringe Filters

These glass fiber filters are designed for high retention efficiency of 98% for 1.6µm / 1.0µm spherical particles. These filters are highly effective for clarifying relatively dirty solutions and serve as an excellent pre-filter when used in conjunction with 0.2µm or 0.45µm filtration systems.

Key Features:
  • Retain fine particles with good flow rate
  • For the collection of suspended solids in portable water and natural and industrial waste
  • Unique design of these filters gives high dirt holding capacity
  • The filters can be stored almost indefinitely without change in color or effect in filter properties


    • Application:
  • For High throughput
  • Sample cleaning
  • Particle removal
  • Removes particulates that interferes with UV/VIS spectrophotometric analysis
  • Can be used alone or in series with another Omicron syringe filter

    • One-Time Purchase

    Specifications

  • Materials of Construction: Filter Media - Borosilicate glass fiber; Housing - Polypropylene
  • Filter Rating: 1.0 µm or 1.6µm
  • Effective Filtration Area: 3.9 cm² for 25mm
  • Sample Volume: < 150ml for 25mm
  • Typical Hold-up Volume (with air purge): <100µl for 25mm
  • Maximum Operating Temperature: 82°C (180°F) at 2.1 bar (210 kPa, 30 psi)
  • Typical Water Flow Rate: 795 ml/min at 1.0 bar (100 kPa, 15 psi)
  • Maximum Operating Pressure:
  • 4.1 bar (410 kPa, 60 psi) at 21-24°C (70-75°F)
  • 2.1 bar (210 kPa, 30 psi) at 82°C (180°F)
